Wireless Communication

• Connectivity

  LTE Cat.1/ 2G FallBack + LoRawan

• Frequency

  LTE FDD : B1, B3, B5, B7, B8, B20, B28
  GSM850 / EGSM900 / DCS1800 / PCS1900
  LoRa : 900.0 and 920.0 MHz

• Transmission Protocol

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  <35s / 15s (with EASYTM)

• Warm Start (TTFF)

  <30s / 5s (with EASYTM)

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  94 * 55 * 23 mm

• Weight

  103g (with event cable)

Hardware (Interface)

• I/O

  6 pin wired connection
  - 2 wires: VCC, GND
  - 2 digital inputs
  - 2 configurable digital outputs

• CAN Port

• LED Indicator

• Features

  Jammer Detection, Circular(255)/Poligonal(30) Geofence, Anti-theft (Door/Ignition Detection), Memory Message: up to 10000, Harsh Acceleration Detection, Firmware Update via OTA (Over-the-Air)

• Motion Sensor

  3-Axis Accelerometer

• User Interface

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 220mA/h (Li-ion)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 90 V

• Power Consumption

  Typical: 40 ~ 50 mA (3 min reporting) @12V
  Sleep mode: less than 5mA @12V
  Deep sleep mode: less than 3mA @12V
  LoRawan: 90mA at 17dBm

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30°C ~ +80°C

• Certification

  Anatel

• Region

  Brazil

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
