Wireless Communication

• Connectivity

  LTE Cat. 1 bis /2G FallBack

• Operating Frequency

  LTE FDD : B1, B3, B5, B7, B8, B20, B28

• Transmission Protocol

• Bluetooth

• Wi-Fi

GNSS

• Receiver Type

  GPS & Glonass
  GPS L1 band(1575.42MHz)
  Glonass L1 band (1601.71MHz)
  SBAS: WAAS, EGNOS, MSAS

• Positioning Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s / 15s with EASTM

• Warm Start (TTFF)

  < 30s, 5s (with EASYTM)

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking: -167dBm / Reacquisition: -161dBm / Acquisition: -149dBm

Physical

• Dimensions

  84.5 x 51.5 x 14mm / 3.33 × 2.03 × 0.55 in

• Weight

  TBD

Hardware (Interface)

• I/O

• CAN Port

• LED Indicators

  LTE / GNSS / Charging operation indication

• Features

  Case open detection based on a light sensor and a magnetic
  Security Alarm
  - Alert: Geo-fencing, Low main battery, main battery’s defect, GPS defect, Route deviation, overspeed, Specific sensors triggered, and Vehicle crash.
  - Emergency: Panic button, Parking lock, and Cut off main power.
  Geo-fencing: Circular up to 255 points / Polygon up to 30 points
  Reports
  - Reporting with adjustable intervals, either by a pre-set (time interval or distance interval) or by Speed threshold.
  - Reports may also be requested at any time from the remote server.
  Data Storage: Up to 10,000 locations, in the event of a transmission failure, minimizing data plan expense.
  Driver’s pattern informs: Triggered by harsh braking, sudden acceleration, or frequent lane change

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Push button for on/off SW

• SIM Card Type

  Nano SIM (4FF)

Battery/Power

• Battery

  5,000mAh (Li-ion) / Rechargeable 3.7V

• Power

• Power Supply

  5V=2A / USB-C Type

• Power Consumption

  Operation Current: 80mA (5 min reporting) @4V
  Deep Sleep Mode: 20uA
  - RF: 21mA at 10dBm

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -20°C ~ +60°C / -4°F ~ 140°F

• Certifications

  NOM

• Region

  LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
