Wireless Communication

• Connectivity

  LTE Cat. M1 / NB-IoT / 2G FallBack

• Frequency

  LTE Cat. M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.X

• wifi

  Only use for Geolocation

GNSS

• Receiver Type

  GPS, GLONASS, BeiDou, Galileo
  SBAS : WAAS, EGNOS, MASA, GAGAN

• Location Accuracy

  +/- 1.5m CEP (*50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  18Hz (Single GNSS) / 5Hz (4 Concurrent GNSS)

• Cold Start (TTFF)

  <24s

• Warm Start (TTFF)

  <2s

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  62(W) x 258(L) x 61(T) mm

• Weight

  714g

Hardware (Interface)

• I/O

  3 Pins : Ground, Power, 1-wire

• CAN Port

• LED Indicator

  Network, GPS, Power

• Features

  BLE 5.X, Wifi

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  External Magnet (Power Pawn)

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Primary Battery 3.6V: 57Ah

• Power

  Up to 10 Years @ 1 report per day

• Power Supply

  12V DC

• Power Consumption

  Active mode : 40~60mA
  Sleep mode (Cell On-GNSS Off) : ~15uA
  Deep sleep mode (Cell Off-GNSS Off) : <10uA

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30°C ~ +85°C

• Certification

  FCC, PTCRB, IC, CE, AT&T, T-Mobile, Verizon, US Cellular, NOM, IFT

• Region

  USA, LATAM, EU
