Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  Cat M1 : B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85
  Cat NB2 : B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85
  2G : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & GLONASS, Galileo, Beidou, QZSS
  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 2.5m (*50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  <35s

• Warm Start (TTFF)

  <30s

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  92(W) x 52(L) x 31(T) mm (3.6 x 2.0 x 1.2 in)

• Weight

  118 g (0.26 lbs)

Hardware (Interface)

• I/O

• CAN Port

• LED Indicator

  On/Off, GPS Status, Cellular Status

• Features

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Power on/off Button, Magnet Mount, Non-Magnet Mount

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Primary Battery 3.6V : 8Ah / 19Ah

• Power

  Battery-Operated

• Power Supply

• Power Consumption

  Active : ~ 220mA
  Deep sleep mode : < 15uA
  Up to 7 years at 1 reporting a day

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -10˚C ~ +60˚C

• Certification

  FCC, PTCRB, CE, T-mobile, US Cellular, NOM

• Region

  USA, LATAM, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
