Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS, GLONASS
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Acquisition -149dBm

Physical

• Dimensions

  97.4(W) x 130(L) x 37.5(T) mm

• Weight

  ST4335: 330g, ST4335+: 358g

Hardware (Interface)

• I/O

  15pin
  6 Inputs
  - 1 Ignition, 3 Inputs Available for Panic button, Door sensor
  - 1 Input/ADC (by configuration)
  - 1-wire interface
  Optional Events
  - 5 Lines : Selectable RS232, Outputs3, 4 and external Power(4.5V)

• CAN Port

• LED Indicator

  Network, GPS

• Features

  Eteranal Power, RS232, Digital Input, Jamming Detection(*Optional), DPA (Dirving Pattern Analysis), Circular/Polygonal Geofencing, Back-up Battery, 1-wire Interface, Ignition Detection (Ignition/Power/Motion), Compatible with ST20U,ST25T

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Power on/off Button

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 7.8 Ah (Li-ion), 3.7V / Opion model - ST4335+: 10.05Ah, ST4335AE: 5.2Ah/10.50Ah, ST4335E:10.50Ah

• Power

  Wired, Battery Operated Tracker

• Power Supply

  DC 8 ~ 38 V (* Main power +/- inversion protection)

• Power Consumption

  Typical : 40mA ~ 60mA
  Sleep mode : < 5mA
  Deep sleep mode : ~ 2mA

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30°C ~ +80°C (with vehicle power) / -20°C ~ +60°C (with back-up battery)

• Certification

  FCC, PTCRB, CE, AT&T, T-Mobile, Verizon, US cellular, NOM

• Region

  USA, LATAM, EU
