Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.X

• wifi

GNSS

• Receiver Type

  GPS + Galileo Concurrent
  GPS, QZSS, GLONASS, Beidou, Galileo
  SBAS : WAAS, EGNOS, MASA, GAGAN
  AGPS (Optional)

• Location Accuracy

  +/- 1.5m CEP -50%

• Update Rate

  18Hz (Single GNSS) / 5Hz (4 Concurrent GNSS)

• Cold Start (TTFF)

  <24s

• Warm Start (TTFF)

  <2s

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -148dBm

Physical

• Dimensions

  62.28(W) × 113.5(L) ×30(T) mm

• Weight

  193.6g

Hardware (Interface)

• I/O

• CAN Port

• LED Indicator

  Network, GPS, Power/Charging

• Features

  Jamming Detection, Tamper Detection (Light sensor)

• Motion Sensor

  6-Axis Accelerometer

• User Interface

  On/Off Power Button, External Power Connector

• SIM Card

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V: 5.9Ah

• Power

  Battery-Operated

• Power Supply

• Power Consumption

  Active mode : 40~50Ma (Interval Time 10min)
  Deep sleep mode : < 55uA
  4 years @ 1 reporting a day

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -10°C ~ +60°C

• Certification

  FCC, PTCRB, AT&T, (VZW,TMO Pending)

• Region

  USA

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
