Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  LTE Cat M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS, Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m CEP, (50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  75(L) x 50.5(W) x 32.5(T) mm / 75(L) x 50.5(W) x 22.5(T) mm

• Weight

  113g (with 3000mAh) / 81g (with 1500mAh)

Hardware (Interface)

• I/O

• CAN Port

• LED Indicator

  Network, GPS, Power

• Features

  Low battery alert

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Power Button, Panic button

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 3,000mAh, (Li-Ion) / *Option : 1,500mAh

• Power

  Battery-Operated

• Power Supply

• Power Consumption

  Active mode : 40~60mA
  Sleep mode : 3.5mA
  Deep Sleep mode : 10uA

Environmental

• Dust and Water Resistant

  IP65

• Operating Temperature

  -20°C ~ +60°C

• Certification

  ANATEL, NOM, IFT, TELCEL

• Region

  Brazil, LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
