Wireless Communication

• Connectivity

  LTE Cat. 1 / 2G FallBack

• Operating Frequency

  LTE FDD : B2, B3, B4, B5, B7, B8, B28, B66
  GSM 800 / EGSM 900 / DCS 1800 / PCS 1900

• Transmission Protocol

  TCP / UDP

• Bluetooth

• Wi-Fi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Positioning Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  90.2(L) x 58(W) x 26.2(T) mm

• Weight

  115g

Hardware (Interface)

• I/O

  14 pin
  2 Inputs : Digital Input or ADC (0-30V) / Available for Panic button, Door sensor
  1 Pin : 1-wire for i-button or Temp sensor
  2 Outputs: Short-Circuit Protection / Open drain / Available for Siren, Vehicle Blocking
  1 Pin : External MIC
  2 Pins: Speaker
  2 Pins : RS232
  4 pins : VCC, GND(2), Ignition

• CAN Port

• LED Indicators

  Network, GPS

• Features

  VoLTE, RS232, Digital Input, Jamming Detection(*Optional), DPA (Dirving Pattern Analysis), Circular/Polygonal Geofencing, Back-up Battery, 1-wire Interface, Ignition Detection (Ignition/Power/Motion), Compatible with ST20U,ST25T

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Pin connector

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 450mA (Ni-MH)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V

• Power Consumption

  Typical mode : 40 ~ 50 mA @12V
  Sleep mode : < 5mA @12V
  Deep sleep mode : < 3mA @12V

Environmental

• Dust & Water Resistance

• Operating Temperature

  -30˚C ~ +85˚C

• Certifications

  FCC(Module), NOM, IFT, TELCEL

• Region

  LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
