Wireless Communication

• Connectivity

  LTE Cat. 1 / 2G

• Frequency

  LTE FDD : B2, B3, B4, B5, B7, B8, B28, B66
  GSM850 / EGSM900 / DCS1800 / PCS1900

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS, GLONASS
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m (*50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Acquisition -149dBm

Physical

• Dimensions

  94(L) * 55(W) * 23(T) mm

• Weight

  103g (with event cable)

Hardware (Interface)

• I/O

  5 pin
  1 Input : Ignition or Input,
  1 Input
  1 Output
  2 pin : VCC, Ground

• CAN Port

• LED Indicator

  Network, GPS

• Features

  Jamming Detection, DPA (Dirving Pattern Analysis), Circular/Polygonal Geofencing, Back-up Battery

• Motion Sensor

  3-Axis Accelerometer

• User Interface

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 220mAh (Li-ion)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V

• Power Consumption

  Active mode : 40~50 mA @12V
  Sleep mode : <4mA @12V
  Deep sleep mode : < 2mA @12V

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30°C ~ +85°C

• Certification

  ANATEL, NOM, IFT

• Region

  Brazil, LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
