Wireless Communication

• Connectivity

  LTE Cat. M1/NB-IoT/ 2G Fallback

• Frequency

  LTE : B2, B3, B4, B5, B12, B13, B28, B66, B85
  GSM : 850,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.x

• wifi

GNSS

• Receiver Type

  GPS, GLONASS, Galileo, BeiDou

• Location Accuracy

  +/- 2m CEP (50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  50(W) x 59(L) x 24(T)mm

• Weight

  55g (with backup battery)

Hardware (Interface)

• I/O

• CAN Port

  OBDII 16pin connector J1962
  Pin 2/10 : J1850(PWM or VPW) protocols
  Pin 7 : ISO 9141-2 & ISO 14230, K-Line
  Pin 15, L-Line
  Pin 6/14 ISO 15765-4 Protocols (CAN)
  *OBD 2 standard connector J1962.
  Heavy Duty truck Data: J1939 ELD, FMS support

• LED Indicator

  Network, GPS

• Features

  Dead Reckoning, J1939 ELD & FMS support, Back-up Battery

• Motion Sensor

  3-Axis Accelerometer

• User Interface

• SIM Card

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 90mA/h (Li-ion)

• Power

  OBDII Port

• Power Supply

  DC 8 V ~ 28 V (* Main power +/- inversion protection.)

• Power Consumption

  Active mode: 120-130mA @12V
  Sleep mode: < 5mA @12V
  Deep sleep mode: < 4mA@12V

Environmental

• Dust and Water Resistant

• Operating Temperature

  -30˚C ~ +85˚C (-22°F~185°F)

• Certification

  FCC, IC, PTCRB, CE, AT&T, T-Mobile, Verizon, Anatel

• Region

  USA, Brazil, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
