Wireless Communication

• Connectivity

  LTE Cat. M1/NB-IoT/2G Fallback

• Frequency

  LTE Cat M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19,B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHzL

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 4.X

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 2.5m CEP (*50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  GPS Sensitivity : -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  74x 46x 25 mm

• Weight

  71g

Hardware (Interface)

• I/O

• CAN Port

  Pin 2/10 : J1850(PWM or VPW) protocols
  Pin 7 : ISO 9141-2 & ISO 14230, K-Line
  Pin 15, L-Line
  Pin 6/14 ISO 15765-4 Protocols(CAN)
  *OBDII standard connector J1962.

• LED Indicator

  Network, GPS

• Features

  DPA (Driving Pattern Analysis), Circular/Polygonal Geofencing, Back-up Battery

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Available at ElA Innovation

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 350mAh (Li-ion)

• Power

  OBDII Port, Back-up Battery

• Power Supply

  DC 8 ~ 33 V (* Main power +/- inversion protection)

• Power Consumption

  Active mode : 120-130mA @12V
  Sleep mode : < 5mA @12V
  Deep sleep mode : < 2mA @12V

Environmental

• Dust and Water Resistant

• Operating Temperature

  -30˚C ~ +80˚C

• Certification

  FCC, CE, IC, PTCRB, RoHS, AT&T, USCellular, Verizon

• Region

  USA, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
