Wireless Communication

• Connectivity

  LTE Cat. M1/NB2-IoT/2G Fallback

• Frequency

  LTE Cat M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  NB-IoT : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  GSM : 850, 900, 1800, 1900MHz

• Transmission Protocol

  TCP / UDP / SMS

• Bluetooth

  N/A

• wifi

  N/A

GNSS

• Receiver Type

  GPS, Glonass, Galileo, Beidou
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 2m CEP (50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

• Warm Start (TTFF)

• Hot Start (TTFF)

• Tracking Sensitivity

  Tracking: -165dBm / Reacquisition: -160dBm / Acquisition: -148dBm

Physical

• Dimensions

  100(W) x 49.5(H) x 18.5(T) mm

• Weight

  78.8 g

Hardware (Interface)

• I/O

• CAN Port

• LED Indicator

  Network, GPS

• Features

  Tamper Detection, Temp sensor

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  On/Off Slide Switch

• SIM Card

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V: 2,750mAh (Li-Ion)

• Power

  Battery-Operated

• Power Supply

  DC 5V, 1A EU type adaptor with USB cable

• Power Consumption

  Active-Max: ~ 220 mA
  GNSS Back-Up: ~ 35 uA
  Deep Sleep: < 15 uA
  Up to 30 Days at 1 Report Per Hour

Environmental

• Dust and Water Resistant

  N/A

• Operating Temperature

  -20°C ~ +60°C

• Certification

  FCC, PTCRB, AT&T, ANATEL

• Region

  USA, Brazil, LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
