Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  LTE Cat M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20,B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20,B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP/ SMS

• Bluetooth

  BLE 5.X

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA
  AGPS (*Optional)

• Location Accuracy

  +/- 2.5m (*50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  18Hz (Single GNSS) / 5Hz (4 Concurrent GNSS)

• Cold Start (TTFF)

  <24s

• Warm Start (TTFF)

  <2s

• Hot Start (TTFF)

  <1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  96 (W) × 130.9(L) ×39.88(T) mm

• Weight

  370g (TBD)

Hardware (Interface)

• I/O

• CAN Port

• LED Indicator

  Network, GPS, Power

• Features

  Jamming Detection, Tamper Detection (Light sensor), Solar Charging

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  1-Wire Temperature Sensor Capable, Self Sustaining Solar Power

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 9 Ah, 3.7V

• Power

  Battery-Operated

• Power Supply

• Power Consumption

  Active mode : 40~60mA
  Deep sleep mode : <10uA (without sensors and GPS_BackUp off)
  Deep sleep mode : <45uA (GPS_Backup on)

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -20˚C ~ +60˚C

• Certification

  FCC, IC, PTCRB, CE, AT&T, T-Mobile, US Cellular, Verizon, NOM, IFT

• Region

  USA, LATAM, EU

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
