Wireless Communication

• Connectivity

  LTE Cat. M1 /NB-IoT/2G FallBack

• Frequency

  LTE Cat. M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS, GLONASS, Galileo, Beidou

• Location Accuracy

  +/- 2m CEP (*50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  10Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Acquisition -149dBm

Physical

• Dimensions

  61(W) x 61(L) x 20.7(T) mm

• Weight

  72 g (with back up battery)

Hardware (Interface)

• I/O

  5pin
  - 1 Pin : Ignition or Input
  - 1 Input : Available for Panic button, Door sensor
  - 1 Output : Short-Circuit Protection, Open drain output, Available for Siren or Vehicle Blocking
  - 2 Pins : Ground, Power

• CAN Port

• LED Indicator

  Network, GPS

• Features

  Circular/Plygonal Geofencing, Back-up Battery, Ignition Detection (Ignition/Power/Motion), DPA (Driving Pattern Analysis)

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Mounting Hole

• SIM Card

  Nano SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 220mAh (Li-Ion)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8V ~ 40V (*Main power +/- inversion protection)

• Power Consumption

  Typical : 30mA ~ 50mA @12V
  Sleep mode : < 5mA @12V
  Deep sleep mode : ~ 2mA @12V

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30˚C ~ +85˚C

• Certification

  FCC, IC, PTCRB, CE, AT&T, T-Mobile, US Cellular, Verizon, Anatel

• Region

  USA, EU
