Wireless Communication

• Connectivity

  LTE Cat. M1 /NB-IoT/2G FallBack

• Frequency

  LTE Cat. M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850/900/1800/1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m CEP (50%, 2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  74(W) x 45(L) x 19.5(T) mm

• Weight

  102 g (with event cable)

Hardware (Interface)

• I/O

  5pin
  - 1 Input: Available for Panic button, Door sensor
  - 1 Output : Short-Circuit Protection, Open drain, Available for Siren, Vehicle Blocking
  - 3 pins : Ground, Ignition,Power

• CAN Port

• LED Indicator

  Network, GPS

• Features

  DPA (Dirving Pattern Analysis), Circular/Polygonal Geofencing, Back-up Battery, Ignition Detection (Ignition/Power/Motion),Jamming Detection(*Optional)

• Motion Sensor

  3-Axis Accelerometer

• User Interface

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 450mAh (Li-Ion)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V (* Main power +/- inversion protection)

• Power Consumption

  Active mode : 40~50mA @12V
  Sleep mode : < 4mA @12V
  Deep sleep mode : < 2mA @12V

Environmental

• Dust and Water Resistant

  IP67

• Operating Temperature

  -30˚C ~ +80˚C

• Certification

  FCC, IC, PTCRB, AT&T, T-Mobile, US Cellular, Verizon, NOM, IFT, TELCEL

• Region

  USA, Brazil, LATAM

Camera

• CPU

• OS

• Forward Camera

• Inward Camera

• Memory

• Mobile App

• ETC
