Wireless Communication

• Connectivity

  LTE Cat. M1/ NB2-IoT/ 2G FallBack

• Frequency

  LTE Cat. M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  EGPRS : 850,900,1800,1900MHz

• Transmission Protocol

  TCP / UDP

• Bluetooth

• wifi

GNSS

• Receiver Type

  GPS & Glonass
  SBAS : WAAS, EGNOS, MASA

• Location Accuracy

  +/- 3m CEP (50%,2D RMS, -130dBm, >6 Sats.)

• Update Rate

  1Hz

• Cold Start (TTFF)

  < 35s

• Warm Start (TTFF)

  < 30s

• Hot Start (TTFF)

  < 1s

• Tracking Sensitivity

  Tracking -167dBm / Reacquisition -161dBm / Acquisition -149dBm

Physical

• Dimensions

  90.2(W) x 58(L) x 26.2(T) mm

• Weight

  115g

Hardware (Interface)

• I/O

  14 pin
  - 2 Inputs : Available for Panic button, Door sensor
  - 1 Pin : 1 Digital Input or ADC
  - 1 Pin : 1-Wire for i-button or Temp sensor
  - 2 Pins : RS232
  - 2 Outputs : Siren / Vehicle Blocking / Open drain
  - 4 pins : VCC, GND(2), Ignition
  - 2 pins : Speaker
  - 1 Pin : Extenal MIC

• CAN Port

• LED Indicator

  Network, GPS

• Features

  External Antena, VoLTE, RS232, 1-wire Interface, Digital Input, DPA (Dirving Pattern Analysis), Back-up Battery, Circular/Polygonal Geofencing, Ignition Detection (Ignition/Power/Motion), Compatible with ST20U,ST25T, Jamming Detection(*Optional)

• Motion Sensor

  3-Axis Accelerometer

• User Interface

  Pin connector

• SIM Card

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V : 450mA (Ni-MH)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V (* Main power +/- inversion protection)

• Power Consumption

  Active mode : 37mA
  Tracking : 27mW
  Always Locate TM: 3.0mW

Environmental

• Dust and Water Resistant

• Operating Temperature

  -30˚C ~ +85˚C

• Certification

  FCC, IC, ANATEL, NOM, IFT

• Region

  USA, Brazil, LATAM
