Wireless Communication

• Connectivity

  LTE Cat.4 / 3G / 2G

• Frequency

  North America
  - LTE-FDD: B2/B4/B5/B7/B12/B13/B17/B25/B26
  - LTE-TDD: B38/B41
  - WCDMA : B1/B2/B4/B5/B8
  - GSM : 850/900/1900
  LATAM
  - LTE-FDD: B1/B3/B5/B7/B8/B28, LTE-TDD: B38/B40/B41
  - WCDMA : B1/B5/B8
  - GSM : 850/900/1800

• Transmission Protocol

  TCP/UDP

• Bluetooth

  BLE 4.2

• wifi

  2.4G/5G Hz 802.11 a/b/g/n/ac

GNSS

• Receiver Type

  GPS, BeiDou, GLONASS

• Location Accuracy

  +/-2.5m CEP-50%

• Update Rate

• Cold Start (TTFF)

  <35s

• Warm Start (TTFF)

  <15s

• Hot Start (TTFF)

  <5s

• Tracking Sensitivity

  Tracking & Navigation: -159dBm / Reacquisition: -156dBm / Cold Start: -148dBm

Physical

• Dimensions

  109.8 * 90 * 33.6 mm

• Weight

  179g / 6.32 oz

Hardware (Interface)

• I/O

  5 wired
  - Power
  - ACC
  - Panic button

• CAN Port

  OBD-II
  - B+
  - CAN BUS
  - GND

• LED Indicator

  Power, Mode Status (Red, Yellow, Blue, Green, White)

• Features

• Motion Sensor

  6-Axis Accelerometer

• User Interface

  Sticker Mounting, USB Type C (Debug/Upgrade)

• SIM Card

  Nano SIM (4FF)

Battery/Power

• Battery

  5F Super CAP

• Power

• Power Supply

  DC 12V or DC 24V / OBD-II (B+, CAN BUS, GND)

• Power Consumption

  Normal mode: TBD @12V
  Parking mode: 5mA @12V
  Power off mode: 150µA @12V

Environmental

• Dust and Water Resistant

• Operating Temperature

  -30°C ~75°C

• Certification

  FCC, Anatel(on-going), NOM(on-going), PTCRB(TBD)

• Region

  USA, LATAM, Brazil, EU

Camera

• CPU

  Octa-core ARM Cortex-A53 cores up to 1.8GHz

• OS

  Android 10.1

• Forward Camera

  FHD1920×1080, 145.6°(D) x 116.9°(H) x 59.7°(V)

• Inward Camera

  FHD1920×1080, 130°(D) x 104°(H) x 56°(V), IR LED

• Memory

  16GB + 3GB
  Single MicroSD (up to 256G support)

• Mobile App

  Companion APP (Android & IOS)

• ETC
