Wireless Communication

• Connectivity

  LTE Cat.M1 / NB-IoT / NTN

• Operating Frequency

  LTE Cat. M1 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85
  LTE Cat. NB2 : B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85
  IoT-NTN : S-Band (B23/B256)/ L-Band (B255)

• Transmission Protocol

  TCP / UDP

• Bluetooth

  BLE 5.3 (2400~2485MHz)

• Wi-Fi

GNSS

• Receiver Type

  GPS 1575.42 ±1.023 (L1) MHz
  GLONASS 1601.7 ±4.2 (L1) MHz
  Galileo 1575.42 ±2.046 (E1) MHz
  BDS 1561.098 ±2.046 (B1I) MHz
  QZSS 1575.42 ±1.023 (L1) MHz
  Supports AGNSS

• Positioning Accuracy

  Autonomous @ open sky 2.5 m

• Update Rate

  1Hz

• Cold Start (TTFF)

  open sky : Autonomous 31.01 s / AGNSS start 10.4 s

• Warm Start (TTFF)

  open sky : Autonomous 30.58 s / AGNSS start 1.53 s

• Hot Start (TTFF)

  open sky : Autonomous 1.6 s / AGNSS start 1.5 s

• Tracking Sensitivity

  Tracking,Reacquisition : -157dBm / Acquisition : -146dBm

Physical

• Dimensions

  94 x 55 x 23 mm / 3.7 × 2.2 × 0.9 in

• Weight

  103g / 3.63 oz (with event cable)

Hardware (Interface)

• I/O

  6pin
  - 1 Pin : Ignition or Digital Input
  - 1 Input : Available for Panic button, Door sensor
  - 2 Outputs : Short-Circuit Protection, Open drain output, Available for Siren, Vehicle Blocking
  - 2 Pins : Ground, Power

• CAN Port

• LED Indicators

  Network, GPS

• Features

  DPA (Driving Pattern Analysis)
  Data storage: up to 10,000 locations
  Power down: sleep or deep sleep (stopping communication)
  Geofencing: Circular(255) / Polygonal(30)
  Back-up Battery: 220mAh
  Jamming Detection(*Optional)
  Driver’s pattern information: Triggered by harsh braking, sudden acceleration, or frequent lane change
  Security Alarm: Alert for Geo-fencing, Low main battery, backup battery’s defect, GPS defect, Route deviation, Overspeed, Specific sensors triggered, and Vehicle crash.
  Emergency for Panic button, Parking lock, and Cut off main power.

• Motion Sensor

  3-Axis Accelerometer

• User Interface

• SIM Card Type

  Micro SIM

Battery/Power

• Battery

  Rechargeable 3.7V, 220mAh (Li-ion)

• Power

  Wired, Back-up Battery

• Power Supply

  DC 8 ~ 33 V (* Main power +/- inversion protection)

• Power Consumption

  Active mode : 40~50 mA@12V
  Sleep mode : < 4mA @12V
  Deep sleep mode: < 2mA@12V

Environmental

• Dust & Water Resistance

  IP67

• Operating Temperature

  -30˚C ~ +80˚C / -22 °F ~ 176 °F

• Certifications

  Skylo, FCC & IC (on-going)

• Region

  USA, Canada, Mexico
